Commercial V type freezer air cooled condensers coils in cold storage
1.Always used in middle and high temperature refrigeration.
2.With external fans, good heat transfer effect, the FNV is suitable for big capacity units.
3.Suitable for refrigerants of R22 R134a, R404A, R407C etc.
4.28MPa gas pressure tested pollution clear is done before delivery.
|
Model |
Capacity (W) |
Cooling surface (m2) |
Fan |
Inlet (mm) |
Outlet (mm) |
||
|
Quantity |
Air flow (m3/h) |
Diameter (w) |
|||||
|
FNV-60(7.5HP) |
17700 |
60 |
2 |
8200 |
400 |
25 |
19 |
|
FNV-80(10HP) |
23600 |
80 |
2 |
14000 |
450 |
25 |
19 |
|
FNV-100(12.5HP) |
29500 |
100 |
2 |
14000 |
450 |
25 |
19 |
|
FNV-120(15HP) |
35400 |
120 |
2 |
14000 |
450 |
32 |
25 |
|
FNV-140(17.5HP) |
41300 |
140 |
2 |
15000 |
500 |
32 |
25 |
|
FNV-160(20HP) |
44300 |
160 |
2 |
25600 |
500 |
32 |
25 |
|
FNV-180(22.5HP) |
47000 |
180 |
2 |
25600 |
600 |
32 |
25 |
|
FNV-200(25.5HP) |
52500 |
200 |
2 |
25600 |
630 |
32 |
25 |
|
FNV-220(27.5HP) |
58500 |
220 |
3 |
22500 |
500 |
32 |
25 |
|
FNV-240(30HP) |
64500 |
240 |
3 |
38400 |
600 |
32 |
28 |
|
FNV-260(32.5HP) |
70500 |
260 |
3 |
38400 |
600 |
32 |
28 |
|
FNV-280(35HP) |
76000 |
280 |
3 |
38400 |
600 |
35 |
28 |
|
FNV-300(37.5HP) |
82500 |
300 |
3 |
38400 |
630 |
35 |
28 |
|
FNV-320(40HP) |
88500 |
320 |
3 |
38400 |
630 |
42 |
32 |
