Hot Sale DL DD DJ Suspended Cold Storage Refrigeration Evaporator
DD series evaporator cold storage is for Medium temperature from -2 to -18 degree, fin space is 6mm.Mainly used in cold storage for vegetables, fruits and frozen meat.
Application Occasions：
D series evaporator is a kind of cooling equipment suitable for various cold storages such as quick freezing fresh keeping and etc. There are three types available: DL DD and DJ which fits for the different cold temperatures. It has compact structure and make full use of warehouse area which can make the storage food cool rapidly and improve the freshness of storage food. DL type is suitable for fresh-keeping storehouse around O degree DD type suitable for chiller room around -18 degree DJ type is suitable for freezer room around -25 degree.
Product Features:
The shell of evaporator cold room is generally made of plastic-sprayed iron plate, food-grade stainless steel plate or embossed aluminum plate. The evaporator cold room has many advantages such as large heat exchange, convenient and simple, high corrosion resistance, and beautiful appearance. The heat exchange coil of the air cooler generally uses internal threads. The heat exchange copper tube is in close contact with the aluminum fin through a hydraulic tube expander, thereby reducing the contact distance and improving the heat transfer coefficient.
After the wholesale evaporator is produced, it goes through a strict decontamination process to ensure the cleanliness of the quality system. The bitzer evaporators uses a high-efficiency outer rotor motor. The motor of this structure has the advantages of large air volume, high wind speed, and long service life. The evaporator for cold storage should be able to Install explosion-proof motors according to different needs.
KITDOO refrigeration equipment company provides customers with professional one-stop cold chain services.
1.Commercial Medium temperature evaporator for cold storage.
2.There are enough space between fans and coils.
3.Exquisite and compact shape design to maximize cold room space utilization
Product Features:
|
Model |
Capacity
(W) |
Cooling surface
(m2) |
Fin Space
(mm) |
Fan |
HeaterVoltage
(v) |
|||
|
Qty |
Size
(mm) |
Air flow
(m3/h) |
Voltage
(v) |
|||||
|
DD-1.3/7 |
1300 |
7 |
6 |
1 |
300 |
1700 |
380 |
220 |
|
DD-2.2/12 |
2200 |
12 |
6 |
2 |
300 |
3400 |
380 |
220 |
|
DD-2.8/15 |
2800 |
15 |
6 |
2 |
300 |
3400 |
380 |
220 |
|
DD-3.7/22 |
3700 |
22 |
6 |
3 |
300 |
5100 |
380 |
220 |
|
DD-5.6/30 |
5600 |
30 |
6 |
2 |
400 |
8000 |
380 |
220 |
|
DD-7.5/40 |
7500 |
40 |
6 |
2 |
400 |
8000 |
380 |
220 |
|
DD-11.2/60 |
11200 |
60 |
6 |
2 |
500 |
12000 |
380 |
220 |
|
DD-14.9/80 |
14900 |
80 |
6 |
2 |
500 |
12000 |
380 |
220 |
|
DD-18.7/100 |
18700 |
100 |
6 |
3 |
500 |
18000 |
380 |
220 |
|
DD-22.4/120 |
22400 |
120 |
6 |
3 |
500 |
18000 |
380 |
220 |
|
DD-26.4/140 |
26400 |
140 |
6 |
3 |
500 |
18000 |
380 |
220 |
|
DD-30.0/160 |
30000 |
160 |
6 |
4 |
500 |
24000 |
380 |
220 |
|
DD-35.0/180 |
35000 |
180 |
6 |
4 |
500 |
24000 |
380 |
220 |
|
DD-37.0/200 |
37000 |
200 |
6 |
4 |
500 |
24000 |
380 |
220 |
|
DD-40.0/220 |
40000 |
220 |
6 |
4 |
500 |
24000 |
380 |
220 |
|
DD-46.0/250 |
46000 |
250 |
6 |
4 |
500 |
24000 |
380 |
220 |
|
DD-50.0/275 |
50000 |
275 |
6 |
4 |
600 |
44000 |
380 |
220 |
|
DD-57.0/310 |
57000 |
310 |
6 |
5 |
600 |
44000 |
380 |
220 |
|
DD-67.0/360 |
67000 |
360 |
6 |
5 |
630 |
45000 |
380 |
220 |
|
DD-81.0/440 |
81000 |
440 |
6 |
5 |
630 |
45000 |
380 |
220 |
Product Detail：
Company Profile：
FOSHAN KITDOO REFRIGERATION EQUIPMENT CO.,LTD. is a comprehensive industrial company specializing in the production of refrigeration equipment integrating research and development, manufacturing, and business services.
